No Comments on Bond Testing between FRP and Rubber in Power Grid Insulators EECI Blogs
Bond Testing between FRP and Rubber in Power Grid Insulators
In power grid insulators, fibre-reinforced plastic/polymers (FRP) and rubberised materials are fused together. If the interface bonding is not uniform, the distribution of the electric field will be adversely affected, which accelerates the ageing of composite insulators and thus, affects the safe operation of transmission lines. Hence, it is important to inspect the bonding between the FRP[…]
Read More23
Feb
Share
No Comments on EECIFLUX MULTI-DIRECTIONAL MAGNETIC PARTICLE INSPECTION SOLUTION EECI Blogs
EECIFLUX MULTI-DIRECTIONAL MAGNETIC PARTICLE INSPECTION SOLUTION
The EECIFLUX multi-directional bench offers an efficient and reliable method to carry out magnetic particle inspection with minimal operator intervention. Highlights of the EECIFLUX multi-directional MPI bench solution: - True multi-directional magnetisation to identify cracks in all orientations in a single shot - AC and HWDC magnetisation - Advanced automation to control and customise test cycles[...]
Read More19
Feb
Share
No Comments on SONODUR 3 PORTABLE HARDNESS TESTING SOLUTION EECI Blogs
SONODUR 3 PORTABLE HARDNESS TESTING SOLUTION
The Sonodur 3 from Institut Dr. Foerster GmbH & Co. KG, provides an unique solution for hardness testing using both UCI (Ultrasonic Contact Impedance) & Leeb methods. The portable & rugged Sonodur 3 provides a reliable hardness testing solution for industries such as automotive, aerospace, heavy engineering, energy & power sector, tools, molds, steel, casting, material treatment, medical,[…]
Read More02
Feb
Share
No Comments on CAST SWASH PLATE INSPECTION OF AUTOMOBILE AIR-CONDITIONER COMPRESSOR EECI Blogs
CAST SWASH PLATE INSPECTION OF AUTOMOBILE AIR-CONDITIONER COMPRESSOR
Every automobile is equipped with an air conditioner, and there is a compressor between the heat exchanger of the indoor unit and the heat exchanger of the outdoor unit. The power of the compressor is transmitted from the power shaft of the reciprocating engine by a belt. However, in the special environment of an automobile,[…]
Read More28
Jan
Share
No Comments on NODULARITY MEASUREMENT BY ULTRASONIC FLAW DETECTOR ADVANSCAN AS-414 EECI Blogs
NODULARITY MEASUREMENT BY ULTRASONIC FLAW DETECTOR ADVANSCAN AS-414
Non-Destructive Nodularity Testing can be done with advanced ultrasonic instrument which is capable of measuring sound velocity. For dedicated nodularity measurement, “EECI” make Advanscan AS-414 provides direct readout of Nodularity percentage in cast iron and other materials based on an entered thickness. With the instrument calibrated for an appropriate frequency transducer, obtain a backwall echo[…]
Read More21
Jan
Share
No Comments on ROTARY ULTRASONIC TUBE/BAR TESTING SYSTEM EECI Blogs
ROTARY ULTRASONIC TUBE/BAR TESTING SYSTEM
EECI & Slickers Technology, Germany are proud to present an advanced ultrasonic rotary solution for the inspection of tubes & bars. The material is tested for: a. Longitudinal defects on the OD (& ID for tubes) b. Transverse defects on the OD (& ID for tubes) c. Oblique defects on the OD (& ID for tubes) d.[…]
Read More05
Jan
Share
No Comments on MAGNETIZING / DEMAGNETIZING COIL EECI Blogs
MAGNETIZING / DEMAGNETIZING COIL
EECI’s Portable AC magnetizing coils are designed for Magnetic Particle Inspection of ferrous metal parts. AC Coils only induce a surface field and are typically not strong enough to set-up a field, AC will only detect ‘surface’ defects. The coils allow for the use of either dry powder or wet fluorescent inspection media and may be[…]
Read More23
Dec
Share
Comments Off on MICROSTRUCTURE & CRACK TESTING OF ROTOR SHAFTS USING EDDY CURRENT EECI Blogs
MICROSTRUCTURE & CRACK TESTING OF ROTOR SHAFTS USING EDDY CURRENT
As a central component of electric motors, rotor shafts ensure the torque transfer from electrical energy to kinetic energy. Without the rotor shaft, an electric vehicle would not move. Withstanding very high loads requires high strength and sophisticated components. Non-destructive eddy current testing is suitable for detecting material and microstructural defects before they make it[…]
Read More17
Dec
Share
No Comments on DIGISCAN DS-324 – ULTRASONIC FLAW DETECTOR EECI Blogs
DIGISCAN DS-324 – ULTRASONIC FLAW DETECTOR
The proven ultrasonic flaw detector Digiscan DS-324 combines EECI’s rich experience, relentless efforts and commitment to provide a product with advanced technology, intuitiveness, uniqueness, affordability and versatile technical features to meet a variety of applications. The Digiscan DS-324 has a rugged, industrial grade metal body which is tough, lightweight & durable, with EMI shielding for[…]
Read More13
Dec
Share
No Comments on SIGMATEST 2.070 EECI Blogs
SIGMATEST 2.070
The SIGMATEST 2.070 from Institut Dr. Foerster GmbH & Co. KG (Germany), is a portable eddy current instrument which measures the electrical conductivity of non-ferromagnetic metals based on the complex impedance of the measuring probe. The measuring range for the instrument is established by calibration. When unknown test pieces are measured, the instrument converts the complex impedance value[…]
Read More
